Resolution - 6MP
WDR - Extreme WDR (150dB)
Audio - Two-way
Corridor Mode - The image can be rotated by 90 degrees for corridor applications.
ONVIF - Easy integration with the wide range of VMS brands

Bullet

Product Matrix

Comparison

Model	A314	A423	A315	A424
Product Type	Fixed Bullet	Zoom Bullet	Fixed Bullet	Zoom Bullet
Maximum Resolution	6MP	6MP	8MP	8MP
Zoom Ratio	-	5x	-	5x
Sensor Size	1/2.4"	1/2.4"	1/2.4"	1/2.8"
Light Type	IR LED: 65m	IR LED: 85m	IR LED: 65m	Adaptive IR LED: 60m
Wide Dynamic Range	Extreme (150 dB)	Extreme (150 dB)	Extreme (150 dB)	Extreme (150 dB)
Maximum Frame Rate	30fps	30fps	30fps	30fps
Audio	-	2-way, Line-in, Line-out	-	2-way, Line-in, Line-out
Maximum fps vs Resolution	30@6MP, 30@5MP, 30@4MP, 30@2MP	30@6MP, 30@5MP, 30@4MP, 30@2MP	20@8MP, 30@6MP, 30@5MP, 30@4MP, 30@2MP	20@8MP, 30@6MP, 30@5MP, 30@4MP, 30@2MP
Multi-Streaming	Quad Streams	Quad Streams	Quad Streams	Triple Streams
Built-in Analytics	-	-	-	Smart Motion Detection
Operating Temperature	-40°C ~ 60°C (-40°F ~ 140°F)	-40°C ~ 60°C (-40°F ~ 140°F)	-40°C ~ 60°C (-40°F ~ 140°F)	-30°C ~ 60°C (-22°F ~ 140°F)
Environmental Casing	Weatherproof (IP68), Vandal proof metal casing (IK10)	Weatherproof (IP68), Vandal proof metal casing (IK10)	Weatherproof (IP68), Vandal proof metal casing (IK10)	Weatherproof (IP67), Vandal proof metal casing (IK10)
Anti-Corrosion	Optional (approximately 2-3 years)	Optional (approximately 2-3 years)	Optional (approximately 2-3 years)	Optional (approximately 2-3 years)
UL Listed	Yes	Yes	Yes	Yes
Cybersecurity	TAICS Level 1, CNS-16120 Level 1	TAICS Level 1, CNS-16120 Level 1	TAICS Level 1	-
NDAA	Yes	Yes	Yes	Yes
Digital Input/Output	-	1/1	-	1/1

Dome

Product Matrix

Comparison

Model	A77	A821	A78	A822
Product Type	Outdoor Fixed Dome	Outdoor Zoom Dome	Outdoor Fixed Dome	Outdoor Zoom Dome
Maximum Resolution	6MP	6MP	8MP	8MP
Zoom Ratio	-	5x	-	5x
Sensor Size	1/2.4"	1/2.4"	1/2.4"	1/2.4"
Light Type	IR LED: 65m	IR LED: 85m	IR LED: 65m	IR LED: 85m
Wide Dynamic Range	Extreme (150 dB)	Extreme (150 dB)	Extreme (150 dB)	Extreme (150 dB)
Maximum Frame Rate	30fps	30fps	30fps	30fps
Audio	2-way, Line-in, Line-out	2-way, Line-in, Line-out	2-way, Line-in, Line-out	2-way, Line-in, Line-out
Maximum fps vs Resolution	30@6MP, 30@5MP, 30@4MP, 30@2MP	30@6MP, 30@5MP, 30@4MP, 30@2MP	20@8MP, 30@6MP, 30@5MP, 30@4MP, 30@2MP	20@8MP, 30@6MP, 30@5MP, 30@4MP, 30@2MP
Multi-Streaming	Quad Streams	Quad Streams	Quad Streams	-
Operating Temperature	-40°C ~ 60°C (-40°F ~ 140°F)	-40°C ~ 60°C (-40°F ~ 140°F)	-40°C ~ 60°C (-40°F ~ 140°F)	-40°C ~ 60°C (-40°F ~ 140°F)
Environmental Casing	Weatherproof (IP68), Vandal proof (IK10)	Weatherproof (IP68), Vandal proof (IK10)	Weatherproof (IP68)	Weatherproof (IP68), Vandal proof (IK10)
Anti-Corrosion	Optional (approximately 2-3 years)	Optional (approximately 2-3 years)	-	-
UL Listed	Yes	Yes	Yes	Yes
Cybersecurity	TAICS Level 1, CNS-16120 Level 1	TAICS Level 1, CNS-16120 Level 1	TAICS Level 1	TAICS Level 1
NDAA	Yes	Yes	Yes	Yes
Digital Input/Output	1/1	1/1	1/1	-

Specifications

Model	A314	A423	A77	A821	A423-00C-V01-261
Type	Fixed Bullet	Zoom Bullet	Fixed Dome	Zoom Dome	Zoom Bullet
Resolution	6MP	6MP	6MP	6MP	6MP
Maximum fps vs Resolution	30@6MP	30@6MP	30@6MP	30@6MP	30@6MP
Lens	Fixed focal, f2.8mm	Zoom, f2.7-13.5mm	Fixed focal, f2.8mm	Zoom, f2.7-13.5mm	Zoom, f2.7-13.5mm
Zoom Ratio	-	5x	-	5x	5x
Corridor Mode	Yes	Yes	Yes	Yes	Yes
Audio	-	2-way, Line-in, Line-out	2-way, Line-in, Line-out	2-way, Line-in, Line-out	2-way, Built-in Microphone, Line-in, Line-out
Analytics	Yes (Deep Learning)	Yes (Deep Learning)	Yes (Deep Learning)	Yes (Deep Learning)	Yes (Deep Learning)
WDR	Extreme WDR (150 dB)	Extreme WDR (150 dB)	Extreme WDR (150 dB)	Extreme WDR (150 dB)	Extreme WDR (150 dB)
UL Certified	Yes	Yes	Yes	Yes	Yes
TAICS	TAICS (Level 1)	TAICS (Level 1)	TAICS (Level 1)	TAICS (Level 1)	-

Solutions

ACTi Unified Solution Architecture consists of NVR servers and CMS

Products

A314

6MP, Fixed Bullet, Day / Night, Extreme WDR, Extreme Low Light Sensitivity, Built-in Analytics
A315

8MP, Fixed Bullet, Day / Night, Extreme WDR, Extreme Low Light Sensitivity, Built-in Analytics
A423

6MP, Zoom Bullet, Day / Night, Extreme WDR, Extreme Low Light Sensitivity, Built-in Analytics, 5x optical
A424

8MP, Zoom Bullet, Day / Night, Adaptive IR, Extreme WDR, Extreme Low Light Sensitivity, Built-in Analytics, 4.3x optical
A77

6MP, Outdoor Fixed Dome, Day / Night, Extreme WDR, Extreme Low Light Sensitivity, Built-in Analytics
A78

8MP, Outdoor Fixed Dome, Day / Night, Extreme WDR, Extreme Low Light Sensitivity, Built-in Analytics
A821

6MP, Outdoor Zoom Dome, Day / Night, Extreme WDR, Extreme Low Light Sensitivity, Built-in Analytics, 5x optical
A822

8MP, Outdoor Zoom Dome, Day / Night, Extreme WDR, Extreme Low Light Sensitivity, Built-in Analytics, 4.3x optical
